Air Nail Gun

F series air nail gun
One of the most frequent use of F30 woodworking, can be used for the type of nail F glue row of nails, the reason why called glue row of nails, is because these nails are glued into a row using glue, the width of the nails 1.25 mm, nail thickness of 1.00 mm, it can be seen that the nails are not the garden, the nail head 2.00 mm × 1.25 mm, the length of the nails have 10 mm, 15 mm, 20 mm, 25 mm, 30 mm The straight nails, you can choose the appropriate straight nails according to the length of the fixing, too short fixing is not firm, too long not only waste, but also easy to hurt people and things.
Main use: For solid wood, plate and other fixed and connected.
T series air nail gun
We introduce T50 here, it uses T series of glued nails, the diameter is thicker than the F30 straight nails, nail width of 1.6 mm, nail thickness of 1.4 mm, nail head 3.00 mm × 1.6 mm, the length of the straight nails 25 mm, 32 mm, 35 mm, 45 mm, 50 mm, we can choose according to the length of the fixing of objects when choosing the appropriate straight nails, too short to fix it is not firm, too long! Not only waste, but also easy to hurt people and things.
Main use: When you feel difficult to use f30, you should consider T50, the wood is harder, less than 1mm of iron, more flimsy wall, T50 can be able to handle. For the thickness is thicker and harder, such as cement, thin steel plate, aluminum plate, you have to use st series steel nails.
ST series air nail gun
Can use the ST series of steel row of nails, of which ST38, ST64 is the most common, the use of nails than T50 straight nails are thicker, nail diameter of 2.2 mm, nail head 4.00 mm × 2.2 mm, straight nail length 18 mm, 25 mm, 32 mm, 38 mm, 45 mm, 50 mm, 57 mm, 64 mm, we can choose, according to the fixing of the When we choose, we can choose the suitable straight nails according to the length of the fixing, too short fixing is not firm, too long not only waste, but also easy to hurt people and things.
Main uses: Hardwood, cement, concrete, bricks and so on can be connected and fixed. Even thin metal plates, such as steel, aluminum, etc. can also be connected, but be sure to pay attention to the safety of hitting metal and very hard objects have a record of injury.
Mosquito nail gun
Gun as the name suggests, the nails are very fine, only 0.63 mm, the general market to buy the model is P625, the first number is the diameter of the nails, the second and third figures is the maximum length of 25 mm, you can hit 12 mm, 15 mm, 18 mm, 20 mm, 22 mm and 25 mm straight nails.
Main use: Fixing sofa, wrapping edge fixing, etc., the use is still relatively wide, in a word, suitable for soft and thin objects.
Code nail gun
Staple machine we have seen, the shape of its nails and the shape of the code nail consistent, code nail gun types are more, there are 1013j, 1022j, 422j, 440k, N815B, which the beginning of the number of 10 said that the shoulder width of 11 millimeters, for the 4 said that the shoulder width of 4 millimeters.
Main applications: Leather, sofa, sheet metal and other joints.

Wear safety glasses or dustproof glasses.
In some working environments, ear protection is required.
Do not use power other than compressed air.
Work under appropriate pressure values.
The gun must not work near volatile substances.
Do not use other unsuitable connectors without permission.
When the gun is not in use, cut off the air supply and remove the nails from the nail holder
Check for loose screws.
You must not pull the trigger outside the nails.
The gun must not be pointed at a person.
Use the specified nails.
The muzzle should be aligned and secured.
When nailing or operating the gun, do not place your hands or body where the nails may strike you.
Do not nail on edges, corners or nails that are too thin.
Nails should not be re-nailed after they have been nailed.
Remove nails left in the nail box or muzzle at the end of the shift.
When using the touch safety, always check that the safety is working properly.
When the gun is working outdoors or on high ground / When operating the gun on a roof or slope, it moves sequentially from bottom to top. There is a risk of slipping if operated in the opposite direction. When nailing, secure the air duct near the workshop. Accidents may occur if the air duct is accidentally pulled or tripped.
The gun cannot be used if some of the gun's control parts (e.g., trigger and buffer) cannot be removed, disassembled, modified, or function properly.
This gun must not be directed to an unguarded area
There are spikes in the virtual gun at all times when using this gun.
This is a working tool of this gun and should be used with caution.
It is forbidden to joke with the shooting gun.
The nail cannot be tightened when the gun is working on any part of the mechanical parts (e.g. trigger and buffer).
